Pump Specifications
Height 498 mm (19.62")
Width 333 mm (13.12")
Depth 376 mm (14.81")
Est. Ship Weight 51.54 lbs (23.4 kgs)
Air Inlet 14 NPTF (1/2")
Inlet 38.1 mm (1½") BSP
Outlet 38.1 mm (1½") BSP
Max. Outlet Pressure 20 - 120 psi (1 - 8.3 bar)
Max. Flow Rate (Flooded) 340.7 lpm (90 gpm)
Max. Size Solids 6.4 mm (1/4")
Fully stainless steel, chemically resistant pumps for the movement of hazardous and harmful material. These pumps are solidly constructed with over sized 316 manifolds for maximum fluid security.
Design Features
- Designed with TOUGHNESS in mind
- Ideal for transfer of chemicals, hazardous waste,
- Move pump from location to location with its compact, rugged design
- Easy access to ball checks and fluid caps for maintenance and repairs
Performance Specifics
- Lube-free operation
- Max. flow rate is 340.7 lpm (90 gpm)
- Max. air pressure is 8.3 bar (120 psig)
- Max. solid passing is 6.4mm (1/4")
- Fully stainless constuction
